LoGS

A logic gate simulator which can be used to design circuits involving the following gates : AND, OR, NOT, NAND, NOR. Controls - Click on the gate and place it on the screen. Inputs for a gate can be changed by clicking on a gate. Wires can be connected by hovering over a pin. Add gates independent of other gates to Execution by hovering over a gate and press the E key, then click the Run button. Move the camera using arrow keys.
